Toyota RAV4 2003
The 2003 Toyota RAV4 carries a braked towing capacity of up to 1500 Kg, but check to ensure this applies to the configuration you're considering.
Toyota RAV4 2003 Price and Specs
Pricing guides
| Toyota RAV4 Model | Body Type | Specs | Price from | Price to | |
|---|---|---|---|---|---|
| Cruiser (4x4) | SUV | 2.4L ULP 4 SP AUTO | $5,720 | $8,030 | |
| Cruiser (4x4) | SUV | 2.0L ULP 4 SP AUTO 4X4 | $4,510 | $6,600 | |
| Cruiser (4x4) | SUV | 2.4L ULP 5 SP MAN | $7,150 | $10,120 | |
| Cruiser (4x4) | SUV | 2.0L ULP 5 SP MAN 4X4 | $3,960 | $5,830 | |
Toyota RAV4 2003 Q&As
Check out real-world situations relating to the Toyota RAV4 2003 here, particularly what our experts have to say about them.
-
Toyota RAV4 2003: Why isn't my gearbox engaging?
It could be the ECU, but I would think it’s more likely at that age that the transmission needs a rebuild. Have a transmission mechanic assess it for you.
Show more -
Toyota RAV4 2003: Known issues?
It has a timing chain, which doesn’t require changing regularly, as a belt does. The only serious problem the RAV4 suffered related to the ECU controlling the automatic transmission, which could fail resulting in erratic shifting.
Show more -
Toyota RAV4 2003: Automatic gearbox problems?
It's a problem with the engine/gearbox management computer and affected cars all over the world. We understand that Toyota redesigned the ECM to fix the problem, so go to a Toyota dealer and ask about a new ECM that has the fix. Don't replace it with another ECM of the same sort that it is currently in your car, that won't fix the problem.
Show more -
Toyota RAV4 2003: Cost of repair after transmission failure?
I think you would have a good case to argue that Toyota should come to the party with at least part of the repair costs. A transmission failure at such low kays is really unacceptable, particularly given the advice that it was caused by a faulty ECM, a problem Toyota knows about.
Show more
Toyota RAV4 2003 Dimensions
Dimensions for the 2003 Toyota RAV4 are dependent on which body type is chosen. The maximum width and height is 1785mm x 1715mm and can vary on the basis of model.
| Toyota RAV4 Model | Body Type | Height x Width x Length | Ground Clearance | |
|---|---|---|---|---|
| Edge (4X4) | SUV | 1665x1735x3800 mm | 190 mm | |
| Extreme | SUV | 1665x1735x3800 mm | 190 mm | |
| CV (4X4) | SUV | 1695x1785x3860 mm | 150 mm | |
| Edge (4X4) | SUV | 1705x1785x4195 mm | 190 mm | |
Toyota RAV4 2003 Towing capacity
The Toyota RAV4 has maximum towing capacity of 1500kg. Some models also offer heavy-duty or towing option packs which can increase towing capacity, as well as options which can hamper towing capacity. Towing capacities can vary wildly on a large number of factors. These include engine, transmission, model, and options chosen. Always check with the manufacturer or in your vehicles handbook before attempting to tow anything.
| Toyota RAV4 Model | Body Type | Specs | Braked Capacity | |
|---|---|---|---|---|
| Edge (4X4) | SUV | 2.0L,ULP,5 SP MAN 4X4 | 1500kg | |
| Extreme | SUV | 2.0L,ULP,5 SP MAN | 1500kg | |
| CV (4X4) | SUV | 2.4L,ULP,5 SP MAN | 1500kg | |
| Edge (4X4) | SUV | 2.0L,ULP,4 SP AUTO 4X4 | 1500kg | |
Toyota RAV4 2003 Fuel consumption
Fuel consumption for the 2003 Toyota RAV4 is dependent on the type of engine, transmission, or model chosen. The Toyota RAV4 currently offers fuel consumption from 8.2 to 9.7L/100km. The Toyota RAV4 is available with the following fuel type: ULP.
| Toyota RAV4 Model | Body Type | Specs | Fuel Consumption | |
|---|---|---|---|---|
| Cruiser (4X4) | SUV | 2.0L,ULP,5 SP MAN 4X4 | 8.2L/100km | |
| Cruiser (4X4) | SUV | 2.0L,ULP,4 SP AUTO 4X4 | 8.3L/100km | |
| Cruiser (4X4) | SUV | 2.4L,ULP,5 SP MAN | 9.3L/100km | |
| Cruiser (4X4) | SUV | 2.4L,ULP,5 SP MAN | 9.4L/100km | |
Toyota RAV4 2003 Wheel size
Wheel size for the 2003 Toyota RAV4 will vary depending on model chosen, although keep in mind that many manufacturers offer alternate wheel sizes as options on many models.The wheel size available will alter the range of tyres available to be fitted. Standard wheel sizes on the Toyota RAV4 spans from 16x6.5 inches.
| Toyota RAV4 Model | Body Type | Front Tyre Size | Front Rim | Rear Tyre Size | Rear Rim | |
|---|---|---|---|---|---|---|
| Edge (4X4) | SUV | 215x70 R16 | 16x6.5 inches | 215x70 R16 | 16x6.5 inches | |
| Extreme | SUV | 215x70 R16 | 16x6.5 inches | 215x70 R16 | 16x6.5 inches | |
| CV (4X4) | SUV | 215x70 R16 | 16x6.5 inches | 215x70 R16 | 16x6.5 inches | |
| Cruiser (4X4) | SUV | 235x60 R16 | 16x7 inches | 235x60 R16 | 16x7 inches | |
