Toyota HiAce 2020

What's on this page

Toyota HiAce 2020

The 2020 Toyota HiAce range of configurations is currently priced from $46,888.

Carsguide Contributing Journalist Mark Oastler had this to say at the time: Most of the winning margins in the 10 judging categories were paper-thin, which is a testament to the overall quality and competence of Australia’s top three commercial vans. As a result, you’d be a happy customer if you bought any of them.

You can read the full review here.

The 2020 Toyota HiAce carries a braked towing capacity of up to 1900 Kg, but check to ensure this applies to the configuration you're considering.

Toyota HiAce 2020 Dimensions

Dimensions for the 2020 Toyota HiAce are dependent on which body type is chosen. The maximum width and height is 1950mm x 2280mm and can vary on the basis of model.

Dimensions for the Toyota HiAce 2020 Dimensions  include 1990mm height, 1950mm width, 5265mm length.
Toyota HiAce Model Body Type Height x Width x Length Ground Clearance
LWB Commercial 1990x1950x5265 mm 179 mm
LWB Exterior Pack Commercial 1990x1950x5265 mm 179 mm
LWB Interior Pack Commercial 1990x1950x5265 mm 179 mm
LWB TOW & Stow Pack Commercial 1990x1950x5265 mm 179 mm
Slwb Commuter GL (colours) People mover 2280x1950x5915 mm 187 mm
Slwb Commuter GL (12 Seats) People mover 2280x1950x5915 mm 187 mm
Slwb Commuter (12 Seats) People mover 2280x1950x5915 mm 187 mm
Commuter GL (12 Seats) People mover 2280x1950x5915 mm 183 mm
See All Toyota HiAce 2020 Dimensions

Toyota HiAce 2020 Price and Specs

The Toyota HiAce 2020 is currently available from $46,888 for the HiAce LWB up to $79,913 for the HiAce Slwb.

Pricing guides

$53,990
Based on 445 cars listed for sale in the last 6 months
Lowest Price
$46,888
Highest Price
$79,913
Toyota HiAce Model Body Type Specs Price from Price to
LWB Commercial 2.8L Diesel 6 SP AUTO $36,100 $46,750
LWB Commercial 2.8L Diesel 6 SP SEQ AUTO $33,100 $43,340
LWB Commercial 2.8L Diesel 6 SP MAN $31,700 $41,470
LWB Commercial 3.5L ULP 6 SP AUTO $32,900 $43,120
Commuter (12 Seats) People mover 2.8L Diesel 6 SP AUTO
Commuter GL (12 Seats) People mover 2.8L Diesel 6 SP AUTO
Slwb Commuter (12 Seats) People mover 2.8L Diesel 6 SP SEQ AUTO
Slwb Commuter GL (12 Seats) People mover 2.8L Diesel 6 SP SEQ AUTO
See All Toyota HiAce 2020 Pricing and Specs

Toyota HiAce 2020 Q&As

Check out real-world situations relating to the Toyota HiAce 2020 here, particularly what our experts have to say about them.

  • Why has my Toyota HiAce van's gearbox failed?

    This does sound like an odd one, to be honest. It’s certainly possible to wear out a clutch in a very short space of time if you drive the car badly, but I’m trying to work out how a gearbox could fail at such a short mileage without there having been something wrong with it from the start. I’d also love to know why Toyota thinks the problem does not constitute a valid warranty claim.

    Has the vehicle been used to tow exceptionally heavy loads? Are there any other extraordinary circumstances that makes Toyota think that the issue is a driver-abuse or neglect scenario?

    I’d start by by-passing your dealership and contacting Toyota Australia’s customer service division. It might also be useful to have the damaged gearbox independently inspected by a specialist who might be able to pin-point the cause of the wear and help determine what happens next. If it can be shown that a component was faulty or simply failed too early, then I’d say you have a good case to pursue a warranty claim.

    Show more
See All Toyota HiAce 2020 Q&As
Disclaimer: You acknowledge and agree that all answers are provided as a general guide only and should not be relied upon as bespoke advice. Carsguide is not liable for the accuracy of any information provided in the answers.

Toyota HiAce 2020 Towing capacity

The Toyota HiAce’s towing capacity ranges from 1400kg to 1900kg. Some models also offer heavy-duty or towing option packs which can increase towing capacity, as well as options which can hamper towing capacity. Towing capacities can vary wildly on a large number of factors. These include engine, transmission, model, and options chosen. Always check with the manufacturer or in your vehicles handbook before attempting to tow anything.

Toyota HiAce Model Body Type Specs Braked Capacity
LWB Commercial 3.5L,ULP,6 SP MAN 1400kg
LWB Commercial 3.5L,ULP,6 SP MAN 1400kg
LWB Exterior Pack Commercial 3.5L,ULP,6 SP MAN 1400kg
LWB Commercial 3.5L,ULP,6 SP AUTO 1500kg
Slwb Commuter GL (colours) People mover 2.8L,Diesel,6 SP SEQ AUTO 1500kg
Slwb Commuter GL (12 Seats) People mover 2.8L,Diesel,6 SP SEQ AUTO 1500kg
Slwb Commuter (12 Seats) People mover 2.8L,Diesel,6 SP SEQ AUTO 1500kg
Commuter GL (12 Seats) People mover 2.8L,Diesel,6 SP AUTO 1500kg
See All Toyota HiAce 2020 Towing Capacity

Toyota HiAce 2020 Fuel consumption

Fuel consumption for the 2020 Toyota HiAce is dependent on the type of engine, transmission, or model chosen. The Toyota HiAce is available with the following fuel types: Diesel and ULP.

Toyota HiAce Model Body Type Specs Fuel Consumption
LWB Commercial 2.8L,Diesel,6 SP MAN 7.5L/100km
LWB Commercial 3.5L,ULP,6 SP MAN 12.4L/100km
Commuter (12 Seats) People mover 2.8L,Diesel,6 SP AUTO 9.5L/100km
Commuter GL (12 Seats) People mover 2.8L,Diesel,6 SP AUTO 9.5L/100km
* Combined fuel consumption See All Toyota HiAce 2020 Pricing and Specs

Toyota HiAce 2020 Interior

Toyota HiAce 2020 Wheel size

Wheel size for the 2020 Toyota HiAce will vary depending on model chosen, although keep in mind that many manufacturers offer alternate wheel sizes as options on many models.The wheel size available will alter the range of tyres available to be fitted.

Toyota HiAce Model Body Type Front Tyre Size Front Rim Rear Tyre Size Rear Rim
LWB Commercial 215x70 R16C 16x7 inches 215x70 R16C 16x7 inches
LWB Commercial 215x70 R16C 215x70 R16C
LWB Exterior Pack Commercial 215x70 R16C 16x7 inches 215x70 R16C 16x7 inches
LWB Interior Pack Commercial 215x70 R16C 16x7 inches 215x70 R16C 16x7 inches
Slwb Commuter GL (colours) People mover 235x65 R16C 235x65 R16C
Slwb Commuter GL (12 Seats) People mover 235x65 R16C 235x65 R16C
Slwb Commuter (12 Seats) People mover 235x65 R16C 235x65 R16C
Commuter GL (12 Seats) People mover 235x65 R16C 16x7 inches 235x65 R16C 16x7 inches
See All Toyota HiAce 2020 Wheel Sizes
