Renault Master

What's on this page

Renault Master

Renault Master Q&As

Check out real-world situations relating to the Renault Master here, particularly what our experts have to say about them.

  • Renault Master: How long is it?

    The Renault Master van is available in a range of dimensions as there are short-, medium- and long-wheelbase options, as well as low-, medium-, and high-roof. The short-wheelbase front-wheel-drive Master is 5048mm long, the front-wheel-drive medium-wheelbase Master is 5548mm, while the long-wheelbase front-wheel-drive Master comes in at 6198mm. The rear-wheel-drive medium-wheelbase Master is also 6198mm long, while the long-wheelbase rear-wheel-drive Master is 6848mm.

    Show more
See All Renault Master Q&As
Disclaimer: You acknowledge and agree that all answers are provided as a general guide only and should not be relied upon as bespoke advice. Carsguide is not liable for the accuracy of any information provided in the answers.

Renault Master Dimensions

The dimensions of the Renault Master Commercial, Ute and People mover vary according to year of manufacture and spec level.

Year Body Type Height x Width x Length Ground Clearance
2021 Commercial 2310x2070x5075 mm 218 mm
2021 Ute 0x2070x0 mm
2021 People mover 2475x2070x6198 mm 200 mm
2020 Ute 0x2070x0 mm
2020 Commercial 2307x2070x5048 mm 219 mm
2020 People mover 2475x2070x6198 mm 200 mm
2019 Commercial 2310x2070x5075 mm 218 mm
2019 People mover 2475x2070x6198 mm 200 mm
2018 Commercial 2307x2070x5048 mm 219 mm
2018 People mover 2475x2070x6198 mm 200 mm
2017 Commercial 2307x2070x5048 mm 219 mm
2017 People mover 2475x2070x6198 mm 200 mm
The dimensions shown above are for the base model. See All Renault Master Dimensions

Renault Master Colours

  • Pearlescent Black
  • Star Grey
  • Glacier White
  • Orange
  • Caribbean Blue
To confirm current colour availability, please check the manufacturer's website. Shown above are the colours for the Renault Master 2019.

Renault Master Towing Capacity

The Renault Master has maximum towing capacity of 3000kg for the latest model available.

Year Body Type Braked Capacity from Braked Capacity to
2021 People mover 2500kg 2500kg
2021 Ute 2500kg 2500kg
2021 Commercial 2500kg 3000kg
2020 People mover 2500kg 2500kg
2020 Ute 2500kg 2500kg
2020 Commercial 2500kg 3000kg
2019 People mover 2500kg 2500kg
2019 Commercial 2500kg 3000kg
2018 People mover 2500kg 2500kg
2018 Commercial 2500kg 3000kg
2017 People mover 2500kg 2500kg
2017 Commercial 2500kg 3000kg
See All Towing Capacity for Renault Master

Renault Master Seats

The following Renault Master Van is available with three seats, including a dual passenger bench seat, with fold down centre seat. All variants come with cloth seat trim. The Master Bus variant is available with twelve seats in a 3-2-3-4 configuration with cloth seat upholstery.

Renault Master Seats
Shown above are seat details for the Renault Master 2019.

Renault Master Wheel Size

The Renault Master has a number of different wheel and tyre options. When it comes to tyres, these range from 225x65 R16 for Commercial in 2021 with a wheel size that spans from —.

Year Body Type Front Tyre Size Front Rim Rear Tyre Size Rear Rim
2021 Commercial 225x65 R16 225x65 R16
2021 People mover 225x65 R16 225x65 R16
2021 Ute 225x65 R16 225x65 R16
2020 Commercial 225x65 R16 16x6.5 inches 225x65 R16 16x6.5 inches
2020 People mover 225x65 R16 16x6.5 inches 225x65 R16 16x6.5 inches
2020 Ute 225x65 R16 16x6.5 inches 225x65 R16 16x6.5 inches
2019 Commercial 225x65 R16 16x6.5 inches 225x65 R16 16x6.5 inches
2019 People mover 225x65 R16 225x65 R16
2018 Commercial 225x65 R16 16x6.5 inches 225x65 R16 16x6.5 inches
2018 People mover 225x65 R16 225x65 R16
2017 Commercial 225x65 R16 16x6.5 inches 225x65 R16 16x6.5 inches
2017 People mover 225x65 R16 225x65 R16
The dimensions shown above are for the base model. See All Renault Master Wheel Sizes

Renault Master Models Price and Specs

The price range for the Renault Master varies based on the trim level you choose. The model range is available in the following body types starting from the engine/transmission specs shown below.

Year Body Type Specs Price from Price to
2021 People mover 2.3L, Diesel, 6 SP AUTOMATED MAN
2021 Ute 2.3L, Diesel, 6 SP AUTOMATED MAN
2021 Commercial 2.3L, Diesel, 6 SP MAN
2021 Commercial 2.3L, Diesel, 6 SP MAN $45,490 $55,990
2021 Ute 2.3L, Diesel, 6 SP AUTOMATED MAN $47,490 $47,490
2021 People mover 2.3L, Diesel, 6 SP AUTOMATED MAN $63,990 $63,990
2020 People mover 2.3L, Diesel, 6 SP AUTOMATED MAN
2020 Ute 2.3L, Diesel, 6 SP AUTOMATED MAN
2020 Commercial 2.3L, Diesel, 6 SP MAN
2019 Commercial 2.3L, Diesel, 6 SP AUTOMATED MAN
2019 People mover 2.3L, Diesel, 6 SP AUTOMATED MAN
2018 Commercial 2.3L, Diesel, 6 SP AUTOMATED MAN
2018 People mover 2.3L, Diesel, 6 SP AUTOMATED MAN
2017 Commercial 2.3L, Diesel, 6 SP AUTOMATED MAN
2017 People mover 2.3L, Diesel, 6 SP AUTOMATED MAN
See All Renault Master Pricing and Specs

Renault Master Fuel Consumption

The Renault Master is available in a number of variants and body types that are powered by Diesel fuel type(s). It has an estimated fuel consumption starting from 8.3L/100km for Commercial /Diesel for the latest year the model was manufactured.

Year Body Type Fuel Consumption* Engine Fuel Type Transmission
2021 Commercial 2.3L Diesel 6 SP MAN
2021 People mover 2.3L Diesel 6 SP AUTOMATED MAN
2021 Ute 2.3L Diesel 6 SP AUTOMATED MAN
2020 Commercial 8.3L/100km 2.3L Diesel 6 SP MAN
2020 People mover 2.3L Diesel 6 SP AUTOMATED MAN
2020 Ute 2.3L Diesel 6 SP AUTOMATED MAN
2019 Commercial 2.3L Diesel 6 SP AUTOMATED
2019 People mover 2.3L Diesel 6 SP AUTOMATED MAN
2018 Commercial 8.3L/100km 2.3L Diesel 6 SP MAN
2018 People mover 2.3L Diesel 6 SP AUTOMATED MAN
2017 Commercial 8.3L/100km 2.3L Diesel 6 SP MAN
2017 People mover 2.3L Diesel 6 SP AUTOMATED MAN
* Combined fuel consumption See All Renault Master Pricing and Specs for 2021
