Ford Transit 2012
The 2012 Ford Transit carries a braked towing capacity of up to 3000 Kg, but check to ensure this applies to the configuration you're considering.
What's on this page
Ford Transit Q&As
Check out real-world situations relating to the Ford Transit here, particularly what our experts have to say about them.
- Ford Transit Custom Sport: Is it available in Australia? Read more
Is the Ford Transit Connect front wheel drive?
Ford's Transit Connect compact panel van range powers the front wheels, rather than being rear wheel drive as per larger more robust vans designed to haul very heavy weights.
How long is a Ford Transit Connect?
Where is the Ford Transit Connect made?
Ford's Transit Connect compact panel vans are built in Turkey and Valencia, Spain.
Ford Transit 2012 Towing capacity
The Ford Transit’s towing capacity ranges from 1500kg to 3000kg. Some models also offer heavy-duty or towing option packs which can increase towing capacity, as well as options which can hamper towing capacity. Towing capacities can vary wildly on a large number of factors. These include engine, transmission, model, and options chosen. Always check with the manufacturer or in your vehicles handbook before attempting to tow anything.
|Ford Transit Model||Body Type||Specs||Braked Capacity|
|LOW (SWB)||Commercial||2.2L,Diesel,6 SP MAN||2000kg|
|ECONETIC LOW (SWB)||Commercial||2.2L,Diesel,6 SP MAN||2000kg|
|LOW (MWB)||Commercial||2.2L,Diesel,6 SP MAN||2000kg|
|LOW (SWB)||Commercial||2.4L,Diesel,6 SP MAN||2000kg|
|12 SEAT||People mover||2.4L,Diesel,6 SP MAN||1500kg|
|12 SEAT||People mover||2.2L,Diesel,6 SP MAN||1500kg|
Ford Transit 2012 Dimensions
Dimensions for the 2012 Ford Transit are dependent on which body type is chosen. The maximum width and height is 1974mm x 2622mm and can vary on the basis of model.
|Ford Transit Model||Body Type||Height x Width x Length||Ground Clearance|
|LOW (SWB)||Commercial||2067x1974x4863 mm||100 mm|
|ECONETIC LOW (SWB)||Commercial||2067x1974x4863 mm||100 mm|
|LOW (MWB)||Commercial||2056x1974x5230 mm||100 mm|
|LOW (SWB)||Commercial||2089x1974x4863 mm||100 mm|
|12 SEAT||People mover||2369x1974x5680 mm||100 mm|
