Volkswagen CRAFTER 2011

What's on this page

Volkswagen CRAFTER 2011

The 2011 Volkswagen Crafter carries a braked towing capacity of up to 2000 Kg, but check to ensure this applies to the configuration you're considering.

The Volkswagen Crafter is also known as the MAN TGE in markets outside Australia.

Volkswagen CRAFTER 2011 Q&As

Check out real-world situations relating to the Volkswagen Crafter here, particularly what our experts have to say about them.

  • How many seats does the vw crafter have?

    Single-cab Crafters sold in Australia are available with three seats in the front, while dual-cab variants can seat up to seven passengers.

    Show more
  • Does the vw crafter have good fuel consumption?

    Volkswagen hasn't provided official fuel consumption figures for the 2018-spec Crafter as there are 59 variants available, and they will have wildly different fuel efficiency. The medium-wheelbase van will surely be much more frugal than the long-wheelbase high-roof model with extended rear overhang, or the heavy duty 4x4 light truck version! Still, Tim Robson saw an average of 10.2-litres per-100km on his short drive around Auckland at the Crafter launch this year.

    Show more
  • How do you reset the vw crafter service light?

    Close all doors, then turn the ignition to position 1. Press the System Selection button repeatedly until the Trip Meter is shown in the multi-function display. Then press the System Selection button repeatedly until the kilometre reading is shown in the multi-function display. Hold the Accept Phone Call button on the steering wheel and, within one second, hold the OK button, keeping both down for 5 seconds. Press the Scroll Forward button to highlight ASSSYST PLUS, then FULL SERVICE, confirming by pressing the OK button. Press the OK button, then repeatedly press the Back button to exit the menu. Switch the ignition off, then on again to confirm the light has been reset.

    Show more
  • Is the vw crafter a 4x4?

    Volkswagen sell their Crafter commercial vans and tray-back utes in front-wheel-drive, rear-wheel-drive and 4x4 formats. With over 50 possible models available there is a dizzying range of Crafters available, in short-wheelbase, medium-wheelbase, and long-wheelbase formats, able to carry up to 4500kg in 4x4 (4MOTION guise).

    Show more
See All Volkswagen Crafter Q&As
Disclaimer: You acknowledge and agree that all answers are provided as a general guide only and should not be relied upon as bespoke advice. Carsguide is not liable for the accuracy of any information provided in the answers.

Volkswagen CRAFTER 2011 Dimensions

Dimensions for the 2011 Volkswagen Crafter are dependent on which body type is chosen. The maximum width and height is 1993mm x 2705mm and can vary on the basis of model.

Dimensions for the Volkswagen CRAFTER 2011 Dimensions  include 2705mm height, 1993mm width, 6940mm length.
Volkswagen Crafter Model Body Type Height x Width x Length Ground Clearance
35 MWB Commercial 2415x1993x5905 mm 176 mm
50 LWB XL Commercial 2703x1993x7300 mm 176 mm
35 LWB Commercial 2705x1993x6940 mm 176 mm
50 LWB Commercial 2705x1993x6940 mm 176 mm
See All Volkswagen CRAFTER 2011 Dimensions

Volkswagen CRAFTER 2011 Price and Specs

VOLKSWAGEN CRAFTER Model Body Type Specs Price from Price to
35 LWB Commercial 2.5L Diesel 6 SP AUTO
35 LWB Commercial 2.5L Diesel 6 SP MAN
35 LWB XL Commercial 2.5L Diesel 6 SP AUTO
35 LWB XL Commercial 2.5L Diesel 6 SP MAN
See All Volkswagen CRAFTER 2011 Pricing and Specs

Volkswagen CRAFTER 2011 Wheel size

Wheel size for the 2011 Volkswagen Crafter will vary depending on model chosen, although keep in mind that many manufacturers offer alternate wheel sizes as options on many models.The wheel size available will alter the range of tyres available to be fitted. Standard wheel sizes on the Volkswagen Crafter spans from 16x6.5 inches.

Volkswagen Crafter Model Body Type Front Tyre Size Front Rim Rear Tyre Size Rear Rim
35 LWB Commercial 225x75 R16 16x6.5 inches 225x75 R16 16x6.5 inches
35 MWB Commercial 225x75 R16 16x6.5 inches 225x75 R16 16x6.5 inches
35 LWB XL Commercial 225x75 R16 16x6.5 inches 225x75 R16 16x6.5 inches
50 MWB Commercial 225x75 R16 16x6.5 inches 225x75 R16 16x6.5 inches
See All Volkswagen CRAFTER 2011 Wheel Sizes

Volkswagen CRAFTER 2011 Towing capacity

The Volkswagen Crafter has maximum towing capacity of 2000kg. Some models also offer heavy-duty or towing option packs which can increase towing capacity, as well as options which can hamper towing capacity. Towing capacities can vary wildly on a large number of factors. These include engine, transmission, model, and options chosen. Always check with the manufacturer or in your vehicles handbook before attempting to tow anything.

Volkswagen Crafter Model Body Type Specs Braked Capacity
35 LWB Commercial 2.5L,Diesel,6 SP MAN 2000kg
35 MWB Commercial 2.5L,Diesel,6 SP MAN 2000kg
50 LWB Commercial 2.5L,Diesel,6 SP AUTO 2000kg
50 LWB XL Commercial 2.5L,Diesel,6 SP MAN 2000kg
See All Volkswagen CRAFTER 2011 Towing Capacity

Volkswagen CRAFTER 2011 Fuel consumption

Fuel consumption for the 2011 Volkswagen Crafter is dependent on the type of engine, transmission, or model chosen. The Volkswagen Crafter is available with the following fuel type: Diesel.

Volkswagen Crafter Model Body Type Specs Fuel Consumption
35 LWB Commercial 2.5L,Diesel,6 SP AUTO
35 LWB Commercial 2.5L,Diesel,6 SP MAN
35 LWB XL Commercial 2.5L,Diesel,6 SP AUTO
35 LWB XL Commercial 2.5L,Diesel,6 SP MAN
* Combined fuel consumption See All Volkswagen CRAFTER 2011 Pricing and Specs
