Height from
Width from
Length from
The height, measured from the ground to the top of the car, ranges from 1860 mm to 1915 mm depending on the variant. The width is 1820 mm across all variants. The length ranges from 5175 mm to 5195 mm. See the table below for a comprehensive list of dimensions for the Mahindra Pik-Up 2020 including the height, width, length and more for each vehicle.
Read More
Show All
Dimension | Metric | Imperial |
---|---|---|
Mahindra Pik-Up Height | 1860 mm | 6 ft 1 in |
Mahindra Pik-Up Width | 1820 mm | 5 ft 12 in |
Mahindra Pik-Up Length | 5175 mm | 16 ft 12 in |
Mahindra Pik-Up Ground clearance unladen | 210 mm | 8 in |
Mahindra Pik-Up Wheelbase | 3040 mm | 9 ft 12 in |
Mahindra Pik-Up Weight | 1755 kg | 3869 lbs |
Mahindra Pik-Up Turning circle | 13.40 m | 43 ft 12 in |
Mahindra Pik-Up Tyre size | 245/75 R16 | 245/75 R16 |
Mahindra Pik-Up Wheel size | 165x406 mm | 6.5x16 in |
Note: The dimensions shown above are for the Mahindra 2Wd S6+, 2.2L, Diesel, 6 SPEED MANUAL. To display dimensions about another variant, click on one of the rows in the table below.
2020 Mahindra Pik-Up | Specs | Height x Width x Length (mm) |
---|---|---|
4Wd | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1915 x 1820 x 5175 |
4Wd S10+ | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1915 x 1820 x 5175 |
Black Edition Mhawk 4Wd | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1915 x 1820 x 5175 |
Black Mhawk 4Wd Limited Edit. | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1915 x 1820 x 5175 |
S10+ 4X4 | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1915 x 1820 x 5175 |
2020 Mahindra Pik-Up | Specs | Height x Width x Length (mm) |
---|---|---|
2Wd | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1860 x 1820 x 5195 |
2Wd S6+ | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1860 x 1820 x 5175 |
2Wd S6+ Pastoral Pack | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1860 x 1820 x 5175 |
2Wd Tradie Pack | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1860 x 1820 x 5195 |
4Wd | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1860 x 1820 x 5195 |
4Wd S6+ | Specs: 2.2L, Diesel, 6 SPEED MANUAL | Height x Width x Length: 1860 x 1820 x 5175 |
