Fiat 500X 2016

What's on this page

Fiat 500X 2016

The 2016 Fiat 500X range of configurations is currently priced from $11,100. Our most recent review of the 2016 Fiat 500X resulted in a score of 6.3 out of 10 for that particular example.

Carsguide Contributing journalist Peter Anderson had this to say at the time: It seems odd to recommend a Fiat 500 of any kind on the grounds of practicality, but the numbers and spec sheet don't lie. It's not a particularly good drive and it's also not small or exceptional value. But it is reasonably cheap to run (cheaper if you seize on a promotional deal), sticks out from the crowd and has its own Italian charms to win you over.

You can read the full review here.

This is what Peter Anderson liked most about this particular version of the Fiat 500X: Good safety gear, Good interior space, Individual looks

The 2016 Fiat 500X carries a braked towing capacity of up to 1200 Kg, but check to ensure this applies to the configuration you're considering.

Fiat 500X 2016 Price and Specs

The Fiat 500X 2016 is currently available from $11,100 for the 500X Pop up to $23,210 for the 500X Lounge.

Pricing guides

$17,155
Based on third party pricing data
Lowest Price
$11,100
Highest Price
$23,210
Fiat 500X Model Body Type Specs Price from Price to
Cross Plus SUV 1.4L PULP 9 SP AUTO $16,200 $22,550
Lounge SUV 1.4L PULP 9 SP AUTO $16,700 $23,210
Pop SUV 1.4L ULP 6 SP $11,900 $17,490
Pop SUV 1.4L ULP 6 SP MAN $11,100 $16,280
See All Fiat 500X 2016 Pricing and Specs

Fiat 500X 2016 Dimensions

Dimensions for the 2016 Fiat 500X are dependent on which body type is chosen. The maximum width and height is 1796mm x 1612mm and can vary on the basis of model.

Dimensions for the Fiat 500X 2016 Dimensions  include 1612mm height, 1796mm width, 4248mm length.
Fiat 500X Model Body Type Height x Width x Length Ground Clearance
POP SUV 1600x1796x4248 mm 163 mm
POP Star SUV 1600x1796x4248 mm 163 mm
Lounge SUV 1612x1796x4248 mm 163 mm
Cross Plus SUV 1612x1796x4248 mm 163 mm
See All Fiat 500X 2016 Dimensions

Fiat 500X 2016 Towing capacity

The Fiat 500X has maximum towing capacity of 1200kg. Some models also offer heavy-duty or towing option packs which can increase towing capacity, as well as options which can hamper towing capacity. Towing capacities can vary wildly on a large number of factors. These include engine, transmission, model, and options chosen. Always check with the manufacturer or in your vehicles handbook before attempting to tow anything.

Fiat 500X Model Body Type Specs Braked Capacity
POP SUV 1.4L,ULP,6 SP MAN 1200kg
POP SUV 1.4L,ULP,6 SP 1200kg
POP Star SUV 1.4L,ULP,6 SP 1200kg
Lounge SUV 1.4L,PULP,9 SP AUTO 1200kg
See All Fiat 500X 2016 Towing Capacity

Fiat 500X 2016 Wheel size

Wheel size for the 2016 Fiat 500X will vary depending on model chosen, although keep in mind that many manufacturers offer alternate wheel sizes as options on many models.The wheel size available will alter the range of tyres available to be fitted. Standard wheel sizes on the Fiat 500X vary from 16x6.5 inches to 18x7 inches.

Fiat 500X Model Body Type Front Tyre Size Front Rim Rear Tyre Size Rear Rim
POP SUV 215x60 R16 16x6.5 inches 215x60 R16 16x6.5 inches
POP Star SUV 215x55 R17 17x7 inches 215x55 R17 17x7 inches
Lounge SUV 225x45 R18 18x7 inches 225x45 R18 18x7 inches
Cross Plus SUV 225x45 R18 18x7 inches 225x45 R18 18x7 inches
See All Fiat 500X 2016 Wheel Sizes

Fiat 500X 2016 Fuel consumption

Fuel consumption for the 2016 Fiat 500X is dependent on the type of engine, transmission, or model chosen. The Fiat 500X currently offers fuel consumption from 5.7 to 6.7L/100km. The Fiat 500X is available with the following fuel types: PULP and ULP.

Fiat 500X Model Body Type Specs Fuel Consumption
Cross Plus SUV 1.4L,PULP,9 SP AUTO 6.7L/100km
Lounge SUV 1.4L,PULP,9 SP AUTO 6.7L/100km
POP SUV 1.4L,ULP,6 SP 5.7L/100km
POP SUV 1.4L,ULP,6 SP MAN 6L/100km
* Combined fuel consumption See All Fiat 500X 2016 Pricing and Specs
