Ford E-Transit 2023 review: 420L BEV Mid Roof - GVM test

Our test vehicle is officially known as the 420L BEV Mid Roof, with 420 denoting its 4.2-tonne GVM (it’s actually 4.25-tonne), L denoting its long wheelbase and Mid Roof being one of two roof heights available, with the other being the optional High Roof variant.

Like its taller stablemate, our test vehicle comes with a 68kWh lithium-ion battery pack, electric motor and single-speed automatic transmission for a list price of $104,990 plus on-road costs.

For that money you could almost buy two diesel Transit 350L Auto equivalents. Even so, the E-Transit brings zero emissions, reduced noise and claimed lower operating and maintenance costs for business operators. With 198kW and 430Nm, it also has the most power and torque of any model in the Transit line-up.

Its large 12-inch touchscreen is the gateway to numerous 'Sync 4'-connected services including the 'Ford Pass' app, which includes 'Power My Trip'. (Image: Mark Oastler)

It comes equipped with 16-inch steel wheels and 235/65R16C tyres plus a full-size spare, along with dark grey bumpers and side-mouldings in areas where scrapes and dents usually occur in hard-working vans. Factory options include dual side-sliding doors and more.

A steel bulkhead/cargo barrier separates the cargo bay from the cabin, which comes standard with a single driver’s seat and twin-passenger bench seat that are all heated.

The 10-way adjustable driver’s seat includes a fold-down inboard armrest, adjustable lumbar support and base-cushion rake.

Ford E-Transit comes equipped with 16-inch steel wheels and 235/65R16C tyres plus a full-size spare. (Image: Mark Oastler)

Plus there’s a two-way adjustable steering wheel, power-folding and heated door mirrors, daytime running lights, three 12-volt accessory outlets, two USB ports, a reversing camera and rear parking sensors.

Its large 12-inch touchscreen is the gateway to numerous 'Sync 4'-connected services including the 'Ford Pass' app, which includes 'Power My Trip'.

By entering a destination, this app can consider the vehicle’s current state of charge in addition to real-time traffic conditions, to help identify charging stops when a customer will need them.

With its hefty 2639kg kerb weight and 4250kg GVM, our test vehicle has a 1611kg payload rating compared to the 350L’s smaller 1142kg. However, the E-Transit is not rated for towing.

The cargo bay, which in Mid Roof form offers 11-cubic metres of load volume, has internal walls that are lined to roof height. It’s accessed from the kerbside through a sliding door with a generous 1300mm opening width.

Rear access is through a pair of barn-doors which open to 270 degrees to optimise forklift access. Large magnets protrude from each side of the body to firmly secure these doors when fully opened which is a welcome safety feature.

With its hefty 2639kg kerb weight and 4250kg GVM, our test vehicle has a 1611kg payload rating compared to the 350L’s smaller 1142kg. (Image: Mark Oastler)

A button located inside the right-hand barn-door switches on a bright external LED overhead light to illuminate rear-loading in poor light conditions.

The load floor, which is protected by a composite liner, is 3533mm long and 1784mm wide with 1392mm between the wheel housings.

That means it can carry three 1165mm-square Aussie pallets or four 1200 x 800mm Euro pallets, secured by up to 10 load-anchorage points. The  1786mm internal height allows tall people to stand with minimal stooping.

The cargo bay, which in Mid Roof form offers 11-cubic metres of load volume, has internal walls that are lined to roof height. (Image: Mark Oastler)

There’s ample cabin storage including a large-bottle holder and bin in each door, plus angled large-bottle holders/bins on each side of the lower dash and small-bottle/cupholders on each side of the upper dash.

There are also three open bins across the top of the dash-pad, a slender vertical bin and pop-out cupholder in the lower centre dash, plus a full-width overhead shelf with numerous compartments.

There are also three open bins across the top of the dash-pad. (Image: Mark Oastler)

Both base cushions on the passenger seat can be tipped forward to access a large hidden storage compartment below.

The centre passenger seat backrest also folds down to a horizontal position to reveal a handy work desk with pen holder, two-cupholders and an elastic strap for securing paperwork.

It offers a comfortable and commanding driving position, thanks to the multi-adjustable seat, two-way steering wheel adjustment and clear eye-lines to the big truck-style door mirrors with lower sections offering wide-angle views.

You don’t need to warm-up the engine to generate cabin heating - it’s instant. And when you get underway it feels more like you're riding in a tram than a van, with its muted electric hum the closest we’ve come to driving a silent commercial vehicle.

With the big battery under the floor it feels firmly planted on the road when unladen, with a low centre of gravity providing good stability when cornering.

The battery weight, combined with E-Transit’s unique four-coil suspension, iron out the bumps and provide a supple ride quality.

Acceleration from standing starts is brisk and smooth in Normal mode, even though you can sense its 2.6-tonne kerb weight's slight reluctance to get moving even with 430Nm of instant torque. At 100km/h, there’s only tyre noise and a little wind-buffeting around the door mirrors.

Acceleration from standing starts is brisk and smooth in Normal mode, even though you can sense its 2.6-tonne kerb weight's slight reluctance to get moving even with 430Nm of instant torque. (Image: Mark Oastler)

We drove the first 100km in Normal mode, during which average consumption was 27kWh/100km. We then switched to Eco mode, which resulted in a drop in performance without a corresponding decrease in consumption. Perhaps you need to drive it longer in Eco to harvest the benefits.

We then switched back to Normal mode for our GVM test. We forklifted 1300kg into the cargo bay which with driver equalled a total payload of 1400kg, which was still more than 200kg under its GVM limit. The rear suspension compressed 50mm with ample travel remaining, while the nose rose 35mm in response.

We forklifted 1300kg into the cargo bay which with driver equalled a total payload of 1400kg, which was still more than 200kg under its GVM limit. (Image: Mark Oastler)

The compressed suspension felt firmer, as you’d expect, but the electric motor hardly noticed this load around town, with acceleration and general response remaining strong if slightly subdued. Energy consumption increased to 28kWh/100km during our load run.

In strictly city driving, which the E-Transit is aimed at, it proved to be a capable workhorse. It can do the job quite economically, too, given that during most of our testing in Normal mode it was operating in the 0-50 per cent ‘power usage’ zone which provides ample performance.

The E-Transit is covered by a five-year/unlimited km warranty plus a separate warranty for the lithium-ion battery and high-voltage electrical components of eight years/160,000km, whichever occurs first.

Capped-price service intervals are 12 months/30,000km, with a total cost for the first five scheduled services of $925 or just $185 per service. Such low maintenance costs are in stark contrast to the purchase price!
