1990 Peugeot 505 Dimensions

GTi, 2.2L, Unleaded Petrol, 5 SPEED MANUAL

Dimension	Metric	Imperial
Peugeot 505 Height	1540 mm	5 ft 1 in
Peugeot 505 Width	1730 mm	5 ft 8 in
Peugeot 505 Length	4898 mm	16 ft 1 in
Peugeot 505 Ground clearance unladen	160 mm	6 in
Peugeot 505 Wheelbase	2900 mm	9 ft 6 in
Peugeot 505 Weight	1405 kg	3097 lbs
Peugeot 505 Turning circle	11.30 m	37 ft 1 in
Peugeot 505 Wheel size	152x356 mm	6x14 in

Note: The dimensions shown above are for the Peugeot GTi, 2.2L, Unleaded Petrol, 5 SPEED MANUAL. To display dimensions about another variant, click on one of the rows in the table below.

All 1990 Peugeot 505 dimensions

Wagon

1990 Peugeot 505	Specs	Height x Width x Length (mm)
(base)	Specs: 2.2L, Unleaded Petrol, 4 SPEED AUTOMATIC	Height x Width x Length: 1544 x 1737 x 4901
GTi	Specs: 2.2L, Unleaded Petrol, 5 SPEED MANUAL	Height x Width x Length: 1540 x 1730 x 4898
