Isuzu D-Max Dimensions 2011

Height from

1635 mm

Width from

1720 mm

Length from

4905 mm

Dimensions for the Isuzu D-Max 2011 include 1635 mm height, 1720 mm width, 4905 mm length.

The height, measured from the ground to the top of the car, ranges from 1635 mm to 1750 mm depending on the variant. The width ranges from 1720 mm to 1800 mm. The length ranges from 4905 mm to 5030 mm. See the table below for a comprehensive list of dimensions for the Isuzu D-Max 2011 including the height, width, length and more for each vehicle.

Read More

Isuzu D-Max Complete Guide Search for other vehicle

Browse by year

Show All

2011 Isuzu D-Max Dimensions

Sx (4X2), 3.0L, Diesel, 5 SPEED MANUAL

Dimension	Metric	Imperial
Isuzu D-Max Height	1635 mm	5 ft 4 in
Isuzu D-Max Width	1720 mm	5 ft 8 in
Isuzu D-Max Length	5025 mm	16 ft 6 in
Isuzu D-Max Ground clearance unladen	195 mm	8 in
Isuzu D-Max Wheelbase	3200 mm	10 ft 6 in
Isuzu D-Max Weight	1505 kg	3318 lbs
Isuzu D-Max Turning circle	12.40 m	40 ft 8 in
Isuzu D-Max Tyre size	215/70 R15	215/70 R15
Isuzu D-Max Wheel size	165x381 mm	6.5x15 in

Note: The dimensions shown above are for the Isuzu Sx (4X2), 3.0L, Diesel, 5 SPEED MANUAL. To display dimensions about another variant, click on one of the rows in the table below.

All 2011 Isuzu D-Max dimensions

Dual Cab

2011 Isuzu D-Max	Specs	Height x Width x Length (mm)
Le 111	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1735 x 1800 x 5030
Limited Edition II (4x4)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1735 x 1800 x 5030
Ls (4X2)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1735 x 1800 x 5030
Ls-M (4X4)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1750 x 1800 x 5030
Ls-U (4X4)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1735 x 1800 x 5030
Sx (4X2)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1660 x 1720 x 4925
Sx (4X4)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1735 x 1800 x 4905
X-Runner (4x2)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1735 x 1800 x 5030
X-Runner (4x4)	Specs: 3.0L, Diesel, 4 SPEED AUTOMATIC	Height x Width x Length: 1735 x 1800 x 5030
Le 111	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1735 x 1800 x 5030
Limited Edition II (4x4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1735 x 1800 x 5030
Ls (4X2)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1735 x 1800 x 5030
Ls-M (4X4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1750 x 1800 x 5030
Ls-U (4X4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1735 x 1800 x 5030
Sx (4X2)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1660 x 1720 x 4925
Sx (4X4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1735 x 1800 x 4905
X-Runner (4x2)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1735 x 1800 x 5030
X-Runner (4x4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1735 x 1800 x 5030

Extra Cab

2011 Isuzu D-Max	Specs	Height x Width x Length (mm)
Sx (4X4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1750 x 1800 x —

Single Cab

2011 Isuzu D-Max	Specs	Height x Width x Length (mm)
Ex (4X4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1725 x 1800 x 5025
EX (4x4) Farm Mate	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1725 x 1800 x 5025
Sx (4X2)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1635 x 1720 x 5025
Sx (4X4)	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1725 x 1800 x 5025
SX (4x4) Farm Mate	Specs: 3.0L, Diesel, 5 SPEED MANUAL	Height x Width x Length: 1750 x 1800 x —
