Height from
Width from
Length from
The height, measured from the ground to the top of the car, is 2635 mm across all variants. The width is 2080 mm across all variants. The length is 6990 mm across all variants. See the table below for a comprehensive list of dimensions for the Toyota Coaster 2024 including the height, width, length and more for each vehicle.
Read More
Show All
Dimension | Metric | Imperial |
---|---|---|
Toyota Coaster Height | 2635 mm | 8 ft 8 in |
Toyota Coaster Width | 2080 mm | 6 ft 10 in |
Toyota Coaster Length | 6990 mm | 22 ft 11 in |
Toyota Coaster Ground clearance unladen | 185 mm | 7 in |
Toyota Coaster Wheelbase | 3935 mm | 12 ft 11 in |
Toyota Coaster Weight | 3730 kg | 8223 lbs |
Toyota Coaster Turning circle | 15.80 m | 51 ft 10 in |
Toyota Coaster Tyre size | 215/70 R17.5 | 215/70 R17.5 |
Toyota Coaster Wheel size | 152x445 mm | 6x17.5 in |
Note: The dimensions shown above are for the Toyota Deluxe, 2.8L, Diesel, 6 SPEED AUTO SEQUENTIAL. To display dimensions about another variant, click on one of the rows in the table below.
2024 Toyota Coaster | Specs | Height x Width x Length (mm) |
---|---|---|
Deluxe | Specs: 2.8L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 2635 x 2080 x 6990 |
Standard | Specs: 2.8L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 2635 x 2080 x 6990 |
