Height from
Width from
Length from
The height, measured from the ground to the top of the car, ranges from 1825 mm to 1860 mm depending on the variant. The width is 1860 mm across all variants. The length is 4825 mm See the table below for a comprehensive list of dimensions for the Isuzu MU-X 2020 including the height, width, length and more for each vehicle.
Read More
Dimension | Metric | Imperial |
---|---|---|
Isuzu MU-X Height | 1825 mm | 5 ft 12 in |
Isuzu MU-X Width | 1860 mm | 6 ft 1 in |
Isuzu MU-X Length | 4825 mm | 15 ft 10 in |
Isuzu MU-X Ground clearance unladen | 220 mm | 9 in |
Isuzu MU-X Wheelbase | 2845 mm | 9 ft 4 in |
Isuzu MU-X Weight | 1992 kg | 4392 lbs |
Isuzu MU-X Turning circle | 11.60 m | 38 ft 1 in |
Isuzu MU-X Tyre size | 245/70 R16 | 245/70 R16 |
Isuzu MU-X Wheel size | 178x406 mm | 7x16 in |
Note: The dimensions shown above are for the Isuzu Ls-M (4X2), 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL. To display dimensions about another variant, click on one of the rows in the table below.
2020 Isuzu MU-X | Specs | Height x Width x Length (mm) |
---|---|---|
Ls-M (4X2) | Specs: 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 1825 x 1860 x 4825 |
Ls-M (4X4) | Specs: 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 1825 x 1860 x 4825 |
Ls-T (4X2) | Specs: 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 1825 x 1860 x 4825 |
Ls-T (4X4) | Specs: 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 1860 x 1860 x 4825 |
Ls-U (4X2) | Specs: 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 1825 x 1860 x 4825 |
Ls-U (4X4) | Specs: 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 1860 x 1860 x 4825 |
Onyx Limited Edition (4X4) | Specs: 3.0L, Diesel, 6 SPEED AUTO SEQUENTIAL | Height x Width x Length: 1860 x 1860 x 4825 |
