Isuzu FTR Dimensions 2021

Height from

2810 mm

Width from

2400 mm

Length from

7405 mm

Dimensions for the Isuzu FTR 2021 include 2810 mm height, 2400 mm width, 7405 mm length.

The height, measured from the ground to the top of the car, is 2810 mm across all variants. The width is 2400 mm The length ranges from 7405 mm to 10740 mm depending on the variant. See the table below for a comprehensive list of dimensions for the Isuzu FTR 2021 including the height, width, length and more for each vehicle.

Read More

Isuzu FTR Complete Guide Search for other vehicle

Browse by year

Show All

2021 Isuzu FTR Dimensions

150-260 (Mlwb), 7.8L, Diesel, 6 SPEED AUTOMATIC

Dimension	Metric	Imperial
Isuzu FTR Height	2810 mm	9 ft 3 in
Isuzu FTR Width	2400 mm	7 ft 10 in
Isuzu FTR Length	10005 mm	32 ft 10 in
Isuzu FTR Wheelbase	6050 mm	19 ft 10 in
Isuzu FTR Weight	5045 kg	11122 lbs
Isuzu FTR Turning circle	20.10 m	65 ft 11 in
Isuzu FTR Tyre size	275/70 R22.5	275/70 R22.5
Isuzu FTR Wheel size	210x572 mm	8.25x22.5 in

Note: The dimensions shown above are for the Isuzu 150-260 (Mlwb), 7.8L, Diesel, 6 SPEED AUTOMATIC. To display dimensions about another variant, click on one of the rows in the table below.

All 2021 Isuzu FTR dimensions

Single Cab

2021 Isuzu FTR	Specs	Height x Width x Length (mm)
150-260 (Lwb)	Specs: 7.8L, Diesel, 6 SPEED AUTOMATIC	Height x Width x Length: 2810 x 2400 x 10740
150-260 (Mlwb)	Specs: 7.8L, Diesel, 6 SPEED AUTOMATIC	Height x Width x Length: 2810 x 2400 x 10005
150-260 (Mwb)	Specs: 7.8L, Diesel, 6 SPEED AUTOMATIC	Height x Width x Length: 2810 x 2400 x 7405
