Height from
Width from
Length from
The height, measured from the ground to the top of the car, is 2810 mm across all variants. The width is 2400 mm The length ranges from 7405 mm to 10740 mm depending on the variant. See the table below for a comprehensive list of dimensions for the Isuzu FTR 2021 including the height, width, length and more for each vehicle.
Read More
Dimension | Metric | Imperial |
---|---|---|
Isuzu FTR Height | 2810 mm | 9 ft 3 in |
Isuzu FTR Width | 2400 mm | 7 ft 10 in |
Isuzu FTR Length | 10005 mm | 32 ft 10 in |
Isuzu FTR Wheelbase | 6050 mm | 19 ft 10 in |
Isuzu FTR Weight | 5045 kg | 11122 lbs |
Isuzu FTR Turning circle | 20.10 m | 65 ft 11 in |
Isuzu FTR Tyre size | 275/70 R22.5 | 275/70 R22.5 |
Isuzu FTR Wheel size | 210x572 mm | 8.25x22.5 in |
Note: The dimensions shown above are for the Isuzu 150-260 (MLWB), 7.8L, Diesel, 6 SPEED AUTOMATIC. To display dimensions about another variant, click on one of the rows in the table below.
2021 Isuzu FTR | Specs | Height x Width x Length (mm) |
---|---|---|
150-260 (LWB) | Specs: 7.8L, Diesel, 6 SPEED AUTOMATIC | Height x Width x Length: 2810 x 2400 x 10740 |
150-260 (MLWB) | Specs: 7.8L, Diesel, 6 SPEED AUTOMATIC | Height x Width x Length: 2810 x 2400 x 10005 |
150-260 (MWB) | Specs: 7.8L, Diesel, 6 SPEED AUTOMATIC | Height x Width x Length: 2810 x 2400 x 7405 |
