Ford Courier

What's on this page

Ford Courier

Ford Courier Q&As

Check out real-world situations relating to the Ford Courier here, particularly what our experts have to say about them.

  • Why does my 2000 Ford Courier billow black smoke when it starts?

    The best way to test the operation of a fuel-injected car’s sensors is to have the vehicle scanned at a workshop with the necessary computer gear. The error codes that are revealed will tell you exactly what’s going on and save you the time and money of replacing bits and pieces until you find the actual culprit.

    As for your symptoms, black smoke from the exhaust usually indicates a too-rich air:fuel mixture which could be the result of worn injectors, incorrect fuel pressure or a faulty temperature sensor. There are other causes, but those are the ones I’d investigate first. After a scan, of course.

    Show more
  • 2002 Ford Courier: Faulty fuel pump.

    There could be a couple of things going on here. The first is that these engines were old-fashioned mechanical fuel-pump units, so they need to be primed. That involves getting all of the air out of the system before they can start to pump diesel again.

    From memory, there’s a manual priming pump in the engine bay (I think near the fuel filter) and the idea is to hand-pump the primer until the plunger starts to feel solid (meaning there’s fuel, not air in there) and then crank the engine till it starts. It can take some time, though. This is precisely why it’s bad form to run an old-school diesel completely out of fuel. Make sure your battery and starter motor are up to the job, too.

    The other possibility is that the new pump needs to be timed to the engine. In these set-ups, the pump not only creates the fuel pressure, it also provides the timing for each injector to fire into each cylinder. If this timing is out, the engine won’t run.

    Beyond that, look for blocked filters, air leaks in the fuel hoses and blocked fuel lines from the tank. And if in doubt, take it to somebody who knows what they’re doing, because having high-pressure fuel spraying around the place is never a good idea.

    Show more
  • Ford Courier 2004: Why does my car keep engaging in 4WD?

    It could be a loose wire on the selector switch, or maybe the switch itself could be faulty.

    Show more
  • Ford Courier 1995: Error message after flat battery

    Disconnecting the battery usually does the trick, but by entering the wrong code so many times might have caused it to shut down. Try a car radio specialist or a Ford dealer.

    Show more
See All Ford Courier Q&As
Disclaimer: You acknowledge and agree that all answers are provided as a general guide only and should not be relied upon as bespoke advice. Carsguide is not liable for the accuracy of any information provided in the answers.

Ford Courier Models Price and Specs

The price range for the Ford Courier varies based on the trim level you choose. Starting at $2,500 and going to $10,890 for the latest year the model was manufactured. The model range is available in the following body types starting from the engine/transmission specs shown below.

Year Body Type Specs Price from Price to
2006 Ute 2.6L, ULP, 5 SP MAN $2,500 $10,890
2005 Ute 2.6L, ULP, 4 SP AUTO $2,400 $10,560
2004 Ute 2.6L, ULP, 5 SP MAN $2,200 $10,120
2003 Ute 2.5L, Diesel, 5 SP MAN $2,300 $6,600
2002 Ute 2.5L, Diesel, 5 SP MAN $2,000 $6,050
See All Ford Courier Pricing and Specs

Ford Courier Dimensions

The dimensions of the Ford Courier Ute vary according to year of manufacture and spec level.

Year Body Type Height x Width x Length Ground Clearance
2006 Ute 1615x1695x4793 mm 179 mm
2005 Ute 1615x1695x4793 mm 179 mm
2004 Ute 1615x1695x4793 mm 179 mm
2003 Ute 1615x1695x4793 mm 179 mm
2002 Ute 1615x1695x4793 mm 179 mm
The dimensions shown above are for the base model. See All Ford Courier Dimensions

Ford Courier Wheel Size

The Ford Courier has a number of different wheel and tyre options. When it comes to tyres, these range from 205x75R14 for Ute in 2006 with a wheel size that spans from 14x5 inches.

Year Body Type Front Tyre Size Front Rim Rear Tyre Size Rear Rim
2006 Ute 205x75R14 14x5 inches 205x75R14 14x5 inches
2005 Ute 205x75R14 14x5 inches 205x75R14 14x5 inches
2004 Ute 205x75R14 14x5 inches 205x75R14 14x5 inches
2003 Ute 205x75R14 14x5 inches 205x75R14 14x5 inches
2002 Ute 195R14C-8ply 14x5 inches 195R14C-8ply 14x5 inches
The dimensions shown above are for the base model. See All Ford Courier Wheel Sizes

Ford Courier Towing Capacity

The Ford Courier has maximum towing capacity of 1800kg for the latest model available.

Year Body Type Braked Capacity from Braked Capacity to
2006 Ute 1800kg 1800kg
2005 Ute 1800kg 1800kg
2004 Ute 1800kg 1800kg
2003 Ute 1800kg 1800kg
2002 Ute 1800kg 1800kg
See All Towing Capacity for Ford Courier

Ford Courier Fuel Consumption

The Ford Courier is available in a number of variants and body types that are powered by Diesel and ULP fuel type(s). It has an estimated fuel consumption starting from 13L/100km for Ute /ULP for the latest year the model was manufactured.

Year Body Type Fuel Consumption* Engine Fuel Type Transmission
2006 Ute 2.5L Diesel 5 SP MAN
2006 Ute 2.6L ULP 5 SP MAN
2005 Ute 2.5L Diesel 5 SP MAN
2005 Ute 2.6L ULP 5 SP MAN
2004 Ute 2.5L Diesel 5 SP MAN
2004 Ute 2.6L ULP 5 SP MAN
2003 Ute 2.5L Diesel 5 SP MAN
2003 Ute 2.6L ULP 5 SP MAN
2002 Ute 2.5L Diesel 5 SP MAN
2002 Ute 13L/100km 2.6L ULP 5 SP MAN
* Combined fuel consumption See All Ford Courier Pricing and Specs for 2006
